Body Structure and Life Process

Unit 5 · CDC textbook pages 49–79

नेपालीमा पढ्नुहोस्

In this unit 7 sections
  1. 5.1 Tissue
  2. Exercise (5.1 Tissue)
  3. 5.2 Human nervous system
  4. Exercise (5.2 Nervous system)
  5. 5.3 Human glandular system
  6. 5.4 Plant hormone
  7. Exercise (5.3 Glands and 5.4 Plant hormone)

You began as one cell, a fertilized egg (a zygote) smaller than the full stop at the end of this sentence. Today you are made of roughly 30 to 40 trillion cells. They are not all alike: some are long and thin and carry messages, some are flat like floor tiles and cover you, some contract, some are full of fat. How does one cell become a body that can run, think, digest dal bhat and blush?

The answer is teamwork at every level. Cells of one kind work together as a tissue. Several tissues make an organ, like the heart. Organs that work together make an organ system, like the circulatory system. All the systems together make an organism: you.

Cella heart muscle cellTissuecardiac muscleOrganthe heartOrgan systemthe circulatory systemOrganisma human being
Figure 5.1 The levels of organization, followed through the heart: one heart-muscle cell; cardiac muscle tissue; the heart, an organ; the circulatory system; a whole human being.

A one-celled (unicellular) living thing, such as an amoeba, does everything inside its single cell: it feeds, breathes, gets rid of wastes and divides. In a multicellular organism the work is shared out. All the activities that keep a living thing alive and let its kind continue, such as nutrition, respiration, photosynthesis (in plants), circulation, excretion and reproduction, are called life processes. The bigger and more complex the animal, the more its organs and systems are specialized to carry out these processes.

In this unit you will meet the tissues of plants and animals, the nervous system that carries messages in a flash, the glands that send slower chemical messages called hormones, and the hormones of plants, which make a seedling bend towards your window.

5.1 Tissue

Every living body is built of small units called cells. A cell is where the work of life actually happens: food is broken down for energy, new materials are made, wastes are formed. That is why the cell is called the structural and functional unit of life.

In a unicellular organism, one cell does every life process: respiration, nutrition, excretion, movement and reproduction. In a multicellular organism, groups of cells specialize. A group of similar cells (sometimes with a few different ones among them) that come from the same origin and work together to do one particular job is called a tissue. The branch of biology that studies tissues is histology.

There are two groups: plant tissues and animal tissues.

Which is the correct order, from the smallest to the largest?

Pick an answer to see why.

Plant tissue

Peel the thin skin from the inside of an onion scale and look at it under a microscope: you see neat rows of brick-like cells. Every part of a plant is built like this, of cells of the same or different kinds. These groups of cells are plant tissues. Depending on whether their cells can still divide, plant tissues are of two kinds: meristematic tissue and permanent tissue.

Plant tissueMeristematiccells keep dividingPermanentcells no longer divideSimpleComplexSpecialapicallateralintercalaryparenchymacollenchymasclerenchymaxylemphloemglandularlaticiferous
Figure 5.2 The kinds of plant tissue.

1. Meristematic tissue

Most cells in a plant stop dividing once they are mature. But some, in the growing parts, keep dividing all their lives. Making new cells by division is called cell division, and a tissue made of actively dividing cells is called a meristematic tissue or meristem (from the Greek meristos, divided).

Meristem cells are built for dividing:

  • thin cell walls,
  • a large nucleus and dense cytoplasm (few or no vacuoles),
  • packed tightly together, with no spaces between the cells (no intercellular spaces).

Meristems are found in the growing regions of a plant, and their job is the growth and development of the plant. According to where they are, there are three kinds: apical, lateral and intercalary.

growing tip (makes auxin)side buds stay smalltip pinched off hereside buds growinto branchestip left on: tallertip pinched off: bushier
Figure 5.3 Activity 5.1 after a week: with its tip, the plant grows taller; without it, the side buds grow into branches.

a) Apical meristem

The apical meristem sits at the very tip of the stem and of the root (apex means tip). Its new cells make the stem and root longer, so the plant grows taller and its roots go deeper. If the tip of a stem is broken off, the stem stops growing in height.

b) Lateral meristem

The lateral meristem lies along the sides of the stem and root, in a ring parallel to their length, just inside the bark. The main one is called the cambium. Its new cells make the stem and root thicker (they increase the girth, or diameter). The rings you see on a cut tree trunk are the wood made by the cambium, one ring each year.

c) Intercalary meristem

The intercalary meristem is found at the base of the internodes, just above the nodes (a node is where a leaf grows from the stem; the part of the stem between two nodes is the internode). It makes the internodes longer. It is important in grasses, bamboo, maize and wheat.

apical meristemat the shoot tip: longer stemintercalary meristemabove a node: longer internodenodeinternodeapical meristemat the root tip: longer rootcut acrossthe stem cut acrosspithvascular bundleslateral meristem: the cambiuma ring of dividing cells (and a second one,the cork cambium, just under the bark)it makes the stem thicker (girth)
Figure 5.4 Where the meristems are. Apical meristems at the tips of the shoot and root make the plant longer; intercalary meristems at the base of the internodes lengthen them; the lateral meristem (the cambium), a ring inside the stem, makes it thicker.

A tree’s trunk becomes thicker year by year. Which meristem does this?

Pick an answer to see why.

2. Permanent tissue

When meristem cells stop dividing, they take on a fixed shape, size and job: they become permanent tissue. In general, cells of permanent tissue do not divide. Their walls may be thin or thick, and the cells may be living or dead.

There are three kinds of permanent tissue: simple permanent tissue, complex permanent tissue and special tissue.

(A) Simple permanent tissue

A simple permanent tissue is made of cells of one kind, and its structure is simple. Simple tissues protect and support the plant, and make and store food. By the structure of their cells, there are three kinds.

nucleusvacuolespace betweencellsnucleuswalls thickat the cornersno spacesthick walllumen:emptyParenchymaliving; thin wallsstores food, makes foodCollenchymaliving; walls thick at cornersstrength that can bendSclerenchymadead; thick, hard wallshard and strong
Figure 5.5 The three simple permanent tissues, cut across, as under a microscope.

a. Parenchyma

  • Living cells with thin walls, oval or rounded (sometimes elongated), with spaces between the cells.
  • Found in the soft parts of the plant: the cortex and pith of stem and root, the flesh of leaves, flowers and fruits; also in xylem and phloem.
  • Stores food (a potato is mostly parenchyma packed with starch).
  • Chlorenchyma is parenchyma with chloroplasts, in leaves and green stems; it makes food by photosynthesis.
  • Aerenchyma is parenchyma with large air spaces between the cells, in water plants such as lotus and water hyacinth; the trapped air helps them float.

b. Collenchyma

  • Living cells whose walls are thickened at the corners with extra cellulose and pectin.
  • Found just under the epidermis of young stems and in the leaf stalks (petioles).
  • Gives the plant mechanical strength with flexibility: a young stem can bend in the wind without breaking.
  • Some collenchyma cells have chloroplasts and make food too.

c. Sclerenchyma

  • Dead cells with very thick walls, hardened by a substance called lignin; no protoplasm, only a narrow empty space (the lumen) in the middle.
  • Found in stems, roots, the veins of leaves, the hard shells of nuts and seeds, and the husks of fruits.
  • Two kinds: long, narrow, pointed fibers, and short, hard sclereids (stone cells).
  • Makes the plant hard, strong and rigid, and lets it stand upright.
Parenchyma Collenchyma Sclerenchyma
Cells living living dead
Wall thin, cellulose thickened at the corners very thick, lignin
Spaces between cells present absent or few absent
Main job stores and makes food; helps water plants float strength with flexibility hardness and strength

Which simple tissue is made of dead cells?

Pick an answer to see why.

(B) Complex tissue

A complex permanent tissue is made of more than one kind of cell, living and dead, working together as one unit. There are two: xylem and phloem. Because they conduct (carry) materials through the plant like pipes, they are called vascular (conducting) tissues.

a. Xylem

Xylem carries water and minerals from the roots up to every part of the plant. It has four kinds of cells:

  1. vessels: long tubes made of cells joined end to end, whose end walls have disappeared;
  2. tracheids: long, narrow cells with tapering ends and small thin areas (pits) in their walls;
  3. xylem fibers: thick-walled supporting cells;
  4. xylem parenchyma: living cells that store food.

Except for the xylem parenchyma, these cells are dead when they work: they are empty pipes and supports with thick, lignified walls. Xylem also makes the plant hard and strong; the wood of a tree is xylem. It runs through the inside of the root, stem and leaves (the veins).

b. Phloem

Phloem carries food (mainly sugar) made in the leaves to all the other parts of the plant, upwards and downwards: to the roots, the growing tips, fruits and seeds. It also has four kinds of cells:

  1. sieve tubes: tubes made of living cells joined end to end; the end walls between them, the sieve plates, are full of holes;
  2. companion cells: narrow cells beside the sieve tubes, with a nucleus, that keep the sieve tubes working;
  3. phloem fibers: thick-walled supporting cells (dead);
  4. phloem parenchyma: living cells that store food.

Except for the fibers, phloem is made of living cells. Phloem is also called bast, and its fibers give the plant some support (jute fibers are phloem fibers).

vesseltracheidfiberparenchymasieve tubecompanion cellfiberparenchymasieve plate:an end wall full of holesopen end(no wall)rings thatkeep it openpitsXylem: mostly dead cellscarries water and minerals up (blue arrow)Phloem: mostly living cellscarries food up and down (green arrows)
Figure 5.6 Xylem and phloem cut lengthwise. Water and minerals go up in the xylem; food goes up and down in the phloem.

A ring of bark is stripped from around a tree trunk. After some weeks the bark just above the ring swells. Why?

Pick an answer to see why.

(C) Special tissue

Some simple tissues are modified to make and give out (secrete) or store away (excrete) particular substances. These are special tissues, and there are two kinds.

a. Glandular tissue

Glandular tissue is made of groups of similar gland cells. Depending on the plant, it secretes enzymes, hormones, digestive juices, oils, resin, gum or nectar. Examples: the oil glands of tulsi (holy basil), whose oil gives it its smell; the glandular hairs of dhaturo; the resin that oozes from a pine tree’s bark.

b. Laticiferous tissue

Laticiferous tissue (also spelled lactiferous) is made of special cells or tubes that contain a milky liquid called latex. Break a leaf or stem of these plants and white latex oozes out: pipal and other Ficus trees, lalupate (poinsettia), katahar (jackfruit), the rubber tree, and aank (Calotropis). Latex protects the plant: it seals wounds and many insects find it sticky or bitter.

The cut end of a jackfruit's thick green stalk, covered in white, sticky latex, with the knobbly skin of the fruit around it
Figure 5.7 The stalk of a freshly picked jackfruit (katahar): white, sticky latex has oozed out over its cut end. A broken leaf of lalupate or pipal does the same. Photo: Vis M, CC BY-SA 4.0

Animal tissue

The tissues of animals are made of animal cells, and each kind does one main job. There are four basic kinds:

  1. epithelial tissue: covers and lines;
  2. muscular tissue: moves;
  3. connective tissue: joins and supports;
  4. nervous tissue: carries messages.
Animal tissueEpithelialcovers and linesMuscularmovesConnectivejoins and supportsNervouscarries messagessquamous (pavement)cuboidal (cubical)columnarglandularskeletalcardiacsmoothsoft (fibrous, adipose)hard (bone, cartilage)fluid (blood, lymph)neuronsneuroglia
Figure 5.8 The four kinds of animal tissue and their types.

(A) Epithelial tissue

Epithelial tissue (epithelium) covers the outside of the body and lines the inside of organs, tubes and cavities. Its cells are packed closely together in sheets, and the sheet sits on a thin layer underneath called the basement membrane. Epithelium covers and protects, and in different places it also secretes, excretes and absorbs.

Epithelium is named by the shape of its cells. The main kinds are:

  1. Squamous (pavement) epithelium: thin, flat cells with many sides, fitted closely together like the paving stones of a courtyard, in a single layer. Its thinness lets substances pass through easily, so it lines the blood vessels and the air sacs (alveoli) of the lungs, and it covers the surfaces of organs such as the heart, liver and kidneys. Jobs: covering, protection, filtering and exchange. (The outer skin is many layers of squamous cells stacked up, which makes it tough.)
  2. Cuboidal (cubical) epithelium: a single layer of cube-shaped cells with round nuclei. It lines the tubules of the kidney, the follicles of the thyroid gland, and the ducts of glands such as the salivary and sweat glands. Jobs: secretion and absorption.
  3. Columnar epithelium: a single layer of tall, pillar-like cells, with the nuclei near the base. It lines the stomach, the intestine and the gall bladder. Jobs: secretion and absorption (in the intestine its cells absorb digested food). In the windpipe, the columnar cells carry tiny moving hairs called cilia, which sweep mucus, dust and germs up and out.
  4. Glandular epithelium: epithelial cells that make and pour out secretions: hormones, enzymes, mucus, saliva, sweat, digestive juices. Glands are made of it, often folded into pits or flasks that open through a duct.
Squamousflat cellslines blood vessels,air sacs of the lungsCuboidalcube-shaped cellskidney tubules, thyroid,ducts of glandsColumnartall cells (some with cilia)stomach, intestine;windpipe (with cilia)Glandularcells that secretee.g. sweat and salivary glandssecretionductbasement membranecilia
Figure 5.9 The kinds of epithelium, each a sheet of cells on a basement membrane.

Why are the walls of the lungs’ air sacs made of squamous epithelium?

Pick an answer to see why.

(B) Muscular tissue

Muscular tissue is made of long, thread-like cells called muscle fibers, which can contract (shorten) and relax. Its job is movement: of the whole body, and of the organs inside it. There are three kinds.

many nuclei, at the edgestripesbranches; dark discs join the cellsspindle-shaped; no stripesSkeletal musclestriped, voluntaryjoined to bones; arms, legsCardiac musclestriped, involuntaryonly in the wall of the heartSmooth musclenot striped, involuntarystomach, intestine, blood vessels
Figure 5.10 The three kinds of muscle tissue, as under a microscope.

a. Skeletal muscle

  • Long, cylindrical fibers, each with many nuclei.
  • Light and dark stripes across them, so it is also called striped or striated muscle.
  • Attached to the bones (by tendons, a connective tissue), so it moves the skeleton: arms, legs, jaw, eyes.
  • Works when we want it to: it is voluntary muscle.
  • Tires after hard work.

b. Cardiac muscle

  • Found only in the wall of the heart.
  • Striped like skeletal muscle, but its cells are branched, each with one nucleus, joined end to end by dark bands.
  • Contracts and relaxes rhythmically all through life without tiring; each contraction is a heartbeat that pumps blood.
  • Involuntary: you can’t stop or start your heart by wishing.

c. Smooth muscle

  • Spindle-shaped cells (thick in the middle, pointed at both ends), each with one nucleus.
  • No stripes, so it is called smooth or unstriped muscle.
  • In the walls of the stomach and intestine (pushing food along), the ureters and bladder, the blood vessels, the uterus, and the iris of the eye.
  • Involuntary: it can’t be controlled at will. Slow, steady and tireless.
Skeletal Cardiac Smooth
Shape of cells long cylinders branched spindles
Nuclei many per fiber one per cell one per cell
Stripes yes yes no
Control voluntary involuntary involuntary
Where attached to bones wall of the heart stomach, intestine, blood vessels, ureter

When you swallow, food moves down the food pipe and through the intestine without your thinking about it. Which muscle does this?

Pick an answer to see why.

(C) Connective tissue

Connective tissue connects and supports the other tissues and organs. Unlike epithelium, its cells are spread out, with a lot of material between them, the matrix. The matrix may be jelly-like, solid or liquid, and contains water, protein fibers and minerals. It is the matrix that makes bone hard and blood liquid. By their structure, connective tissues are of three kinds: soft, hard and fluid.

Connective tissueSoftLooseDenseHardFluidareolaradiposetendonligamentbonecartilagebloodlymph
Figure 5.11 The kinds of connective tissue.

a. Soft connective tissue

The cells lie loosely in a matrix with plenty of fibers; some kinds store a lot of fat.

i. Fibrous connective tissue

Made of fibers, loosely or tightly packed.

  • Loose (areolar) connective tissue is the simplest and most widespread. It lies in the dermis, joining the skin to the muscles below, and around blood vessels, nerves and muscles, filling the spaces between organs and holding them in place.
  • Dense connective tissue has tightly packed fibers and is very strong. It forms the tough coverings around the kidneys, liver, glands and muscles, and two important cords:
    • a tendon joins a muscle to a bone;
    • a ligament joins a bone to a bone (at a joint); ligaments are a little elastic.

ii. Adipose connective tissue

A loose connective tissue with few fibers, whose cells are filled with fat. It is found under the skin and around organs such as the kidneys and heart. It stores energy, acts as a cushion that protects the organs inside, and keeps the body warm (fat is a poor conductor of heat).

b. Hard connective tissue

Bone and cartilage are the hard connective tissues: they make up the skeleton and support the body.

  • Bone is very hard because calcium (as calcium phosphate) is laid down in its matrix, along with protein fibers that stop it from being brittle. Its living cells are called osteocytes, and the bone is wrapped in a thin membrane, the periosteum. The bones of the skull, limbs and backbone are made of strong, hard bone.
  • Cartilage is firm but bendable; its cells are called chondrocytes. It is found in the tip of the nose, the outer ear, the larynx and windpipe in the neck, the discs between the vertebrae, and at the ends of long bones, where it reduces friction at the joints and absorbs shocks.

In an unborn baby, much of the skeleton is first made of cartilage; it slowly hardens into bone as calcium salts are laid down. That is why a baby is born with about 300 bones and soft spots in the skull, and an adult has 206: some bones fuse together as they harden.

c. Fluid connective tissue

Some connective tissues are liquid. They flow around the body, carry materials and link the systems together. There are two: blood and lymph.

i. Blood

Blood is a red, liquid connective tissue that carries materials from one part of the body to another. About 55 % of it is a pale yellow liquid, plasma, and 45 % is blood cells. Plasma is about 90 % water and 10 % dissolved substances; it carries digested food, enzymes, hormones and wastes. The blood cells are of three kinds:

  • Red blood cells contain hemoglobin, which takes up oxygen in the lungs and carries it to all parts of the body; they also help carry carbon dioxide back to the lungs.
  • White blood cells fight and destroy harmful germs (pathogens).
  • Platelets help the blood to clot at a wound, so we don’t keep bleeding.
Red blood cell (erythrocyte)from abovefrom the side:thin in the middle• no nucleus: more roomfor hemoglobin• dented on both sides(biconcave): bends to squeezethrough capillaries• about 7.5 µm acrossPlateletstiny pieces of a big cell,2–3 µm, no nucleusWhite blood cells (leucocytes): bigger, with a nucleus, no hemoglobingranular (granules in the cytoplasm)neutrophilnucleus in 3–5 lobeseosinophilnucleus in 2 lobesbasophildark granulesnon-granular (no granules)lymphocyteone big round nucleusmonocyte (biggest)kidney-shaped nucleus
Figure 5.12 The cells of blood, roughly to scale: red blood cells, the five kinds of white blood cell, and platelets.

ii. Lymph

Lymph is a colorless liquid connective tissue that flows in thin tubes called lymph vessels. It forms from the liquid part of the blood: some plasma leaks out of the thin capillaries into the spaces between the cells, bathing them. Most of it goes back into the blood; the rest drains into lymph vessels and is called lymph. Lymph has no red blood cells and no hemoglobin; it has plasma and many white cells called lymphocytes. It protects the body against infection (the lymph nodes, which swell when you have a sore throat, are where germs are trapped), brings nutrients to the tissues, and carries away wastes.

(D) Nervous tissue

Nervous tissue receives messages, carries them and directs the organs of the body, so that they work together. It is made of nerve cells (neurons), the basic units of the nervous system, held in place, protected and fed by supporting cells called neuroglia (glial cells).

Neuron or nerve cell

A neuron has three main parts:

  1. the cell body (cyton), which holds the nucleus; cell bodies look gray (ash-colored);
  2. dendrites: short, branched threads that grow out from the cell body; they receive messages (from other neurons or from sense cells) and carry them towards the cell body;
  3. the axon: one long thread from the cell body that carries messages away from the cell body to the next neuron, a muscle or a gland; it ends in branched axon terminals.

Many axons are wrapped in a fatty, whitish myelin sheath (in the nerves of the body it is made by Schwann cells), with small gaps along it called nodes of Ranvier. The myelin insulates the axon and makes messages travel much faster. Because of the myelin, bundles of axons look white.

So a message always travels one way: dendrites → cell body → axon → axon terminals → next cell. When you stub your toe, a chain of neurons carries the message to your brain, and you feel the pain.

dendritescell body (cyton)holds the nucleusaxonmyelin sheath (Schwann cells)node of Ranvieraxon terminalspass the message onthe message (nerve impulse) travels this way
Figure 5.13 A neuron. The message comes in through the dendrites and goes out along the axon.

Which part of a neuron carries the message away from the cell body?

Pick an answer to see why.

Exercise (5.1 Tissue)

1. Choose the correct answer

(i) Which kind of tissue has cells that can divide?

Pick an answer to see why.

(ii) Which tissue lines the tubules of the kidney and the ducts of the salivary glands?

Pick an answer to see why.

(iii) Where is meristematic tissue found in a plant?

Pick an answer to see why.

(iv) In which organ is cardiac muscle found?

Pick an answer to see why.

(v) What does a plant use its vascular tissue for?

Pick an answer to see why.

2. Give reasons

a.

Blood is called a liquid (fluid) connective tissue.

Answer

Blood is a connective tissue because, like other connective tissues, its cells (red cells, white cells, platelets) are spread out in a large amount of matrix, and it links all the parts and systems of the body by carrying materials between them. Its matrix, the plasma, is a liquid, so it is a liquid connective tissue.

b.

A plant stops growing taller when its tip is cut off.

Answer

The tip of the stem holds the apical meristem, whose dividing cells make the stem longer. When the tip is cut off, the apical meristem is removed, so no new cells are added at the top and the stem stops growing in height. (The side buds then grow into branches instead.)

c.

A white liquid comes out when a leaf of lalupate (poinsettia) is broken off.

Answer

Lalupate has laticiferous tissue, special cells and tubes that contain a milky liquid called latex. When a leaf is broken, these tubes are cut and the latex oozes out. It helps seal the wound and protects the plant.

d.

Xylem is called a complex permanent tissue.

Answer

Xylem is permanent because its cells have stopped dividing and have a fixed shape and job. It is complex because it is made of more than one kind of cell (vessels, tracheids, xylem fibers and xylem parenchyma, some dead and some living) working together as one unit to carry water and minerals.

3. Write the differences

i.

Muscular tissue and connective tissue

Answer
Muscular tissue Connective tissue
Made of long muscle fibers packed closely together. Cells are spread out in a large amount of matrix.
Little matrix between the cells. Plenty of matrix: liquid, jelly-like or solid.
Its job is movement, by contracting and relaxing. Its job is to join, support, protect and carry materials.
Kinds: skeletal, cardiac, smooth. Kinds: soft, hard (bone, cartilage), fluid (blood, lymph).
ii.

Xylem and phloem

Answer
Xylem Phloem
Carries water and minerals. Carries food (sugar) made in the leaves.
Carries them in one direction: upwards, from the roots. Carries food both upwards and downwards.
Mostly dead cells (only xylem parenchyma is living). Mostly living cells (only phloem fibers are dead).
Parts: vessels, tracheids, xylem fibers, xylem parenchyma. Parts: sieve tubes, companion cells, phloem fibers, phloem parenchyma.
Forms the wood; gives hardness. Also called bast; found in the bark.
iii.

Meristematic tissue and permanent tissue

Answer
Meristematic tissue Permanent tissue
Cells keep dividing. Cells have stopped dividing.
Cells have thin walls, a large nucleus, dense cytoplasm and few or no vacuoles. Cells may have thin or thick walls and usually large vacuoles.
No spaces between the cells. Spaces between the cells may be present.
All cells are living. Cells may be living or dead.
Found in the growing regions: tips, cambium, nodes. Found in all the other parts of the plant.
Job: growth. Jobs: protection, support, conduction, making and storing food.
iv.

Sclerenchyma and collenchyma

Answer
Sclerenchyma Collenchyma
Dead cells. Living cells.
Walls thickened all over, with lignin. Walls thickened only at the corners, with cellulose and pectin.
Cells long and narrow (fibers) or short (sclereids), with a narrow empty lumen. Cells polygonal, with a nucleus and cytoplasm.
Makes the plant hard and rigid. Gives strength with flexibility.
In nut shells, seed coats, fibers of stems and leaf veins. Under the epidermis of young stems and in leaf stalks.

4. Answer the following questions

a.

What is a life process? Describe it with examples.

Answer

The activities a living thing must carry out to stay alive and to keep its kind going are called life processes. Examples:

  • Nutrition: taking in or making food (a plant makes food by photosynthesis; we eat).
  • Respiration: breaking down food to release energy.
  • Circulation: carrying materials around the body (blood in animals, xylem and phloem in plants).
  • Excretion: removing waste products (we pass urine and breathe out carbon dioxide).
  • Reproduction: producing young of the same kind.

In a unicellular organism, one cell does all of these; in a multicellular organism, special tissues, organs and systems do them.

b.

Draw a concept map of the classification of plant tissues and animal tissues, with examples.

Answer

Plant tissues (as in Figure 5.2):

  • Meristematic: apical (tips of stem and root), lateral (cambium), intercalary (base of internodes).
  • Permanent: simple (parenchyma, e.g. potato flesh; collenchyma, e.g. leaf stalks; sclerenchyma, e.g. coconut husk), complex (xylem, e.g. wood; phloem, e.g. bast), special (glandular, e.g. tulsi oil glands; laticiferous, e.g. lalupate).

Animal tissues (as in Figure 5.8):

  • Epithelial: squamous (lining of blood vessels), cuboidal (kidney tubules), columnar (lining of the intestine), glandular (sweat glands).
  • Muscular: skeletal (biceps), cardiac (heart wall), smooth (stomach wall).
  • Connective: soft (areolar under the skin; adipose; tendons, ligaments), hard (bone, cartilage), fluid (blood, lymph).
  • Nervous: neurons and neuroglia (brain, spinal cord, nerves).
c.

Explain meristematic tissue with a diagram.

Answer

Meristematic tissue is a plant tissue made of cells that keep dividing. Its cells have thin walls, a large nucleus, dense cytoplasm and few or no vacuoles, and are packed together with no spaces between them. It is found in the growing regions and makes the plant grow. Three kinds, by position (draw as in Figure 5.4):

  • Apical meristem, at the tips of the stem and root: makes them longer.
  • Lateral meristem (cambium), in a ring along the sides of the stem and root: makes them thicker.
  • Intercalary meristem, at the base of the internodes: makes the internodes longer.
d.

What is permanent tissue? Describe its kinds briefly, with examples.

Answer

A permanent tissue is made of cells that have lost the power to divide and have taken a fixed shape, size and job. Its cells may be living or dead. There are three kinds:

  1. Simple permanent tissue, made of one kind of cell: parenchyma (stores and makes food; potato), collenchyma (strength with flexibility; leaf stalks) and sclerenchyma (hardness; coconut husk, seed coats).
  2. Complex permanent tissue, made of several kinds of cell working together: xylem (carries water and minerals up; wood) and phloem (carries food; bast).
  3. Special tissue, which makes or stores particular substances: glandular tissue (oils, resin, nectar; tulsi, pine) and laticiferous tissue (latex; lalupate, pipal, rubber).
e.

Draw neat, labeled diagrams of sclerenchyma, collenchyma and parenchyma, and list their functions.

Answer

Draw them as in Figure 5.5: parenchyma as rounded cells with thin walls, a nucleus, a vacuole and spaces between them; collenchyma as many-sided cells with thick corners and no spaces; sclerenchyma as cells with very thick walls and a tiny empty lumen.

  • Parenchyma: stores food; makes food by photosynthesis (as chlorenchyma); helps water plants float (as aerenchyma).
  • Collenchyma: gives mechanical strength and flexibility to young stems and leaf stalks; some make food.
  • Sclerenchyma: makes the plant hard, strong and rigid; forms the hard coverings of seeds and nuts.
f.

Write the functions of epithelial tissue.

Answer
  1. Covers and protects the body and its organs from injury, germs and drying out (skin).
  2. Lines the tubes and cavities inside the body (blood vessels, food canal, windpipe).
  3. Secretes substances such as mucus, enzymes, sweat and hormones (glandular epithelium).
  4. Absorbs substances, such as digested food in the intestine (columnar epithelium).
  5. Excretes wastes (kidney tubules) and lets substances pass by filtering and diffusion (squamous epithelium of the air sacs and capillaries).
  6. Ciliated epithelium of the windpipe sweeps out dust and mucus.
g.

Prepare a chart of animal tissues and write where each is found.

Answer
Tissue Kind Where it is found
Epithelial squamous lining of blood vessels and lung air sacs; covering of organs; outer skin (many layers)
cuboidal kidney tubules, thyroid gland, ducts of glands
columnar lining of stomach, intestine, gall bladder; windpipe (ciliated)
glandular sweat, salivary and other glands
Muscular skeletal attached to bones (arms, legs)
cardiac wall of the heart
smooth walls of stomach, intestine, ureter, blood vessels
Connective areolar under the skin, around blood vessels and organs
adipose under the skin, around kidneys and heart
tendon, ligament muscle to bone; bone to bone at joints
bone, cartilage skeleton; nose, ear, larynx, ends of bones
blood, lymph in blood vessels and lymph vessels
Nervous neurons, neuroglia brain, spinal cord, nerves
h.

Observe the figure and answer the questions.

ABCD
Figure 5.14
  • i.Identify the figure.
  • ii.Name the parts marked A, B, C and D.
  • iii.Write the function of this tissue.
  • iv.Write the importance of this tissue to plants.
Answer
  • i.It shows the vascular (complex permanent) tissues, xylem (left) and phloem (right), cut lengthwise.
  • ii.A: xylem vessel; B: sieve tube; C: companion cell; D: sieve plate.
  • iii.Xylem carries water and minerals from the roots up to the leaves and all other parts; phloem carries food made in the leaves to all parts of the plant, upwards and downwards.
  • iv.Without them, the leaves would get no water for photosynthesis and the roots, flowers and fruits would get no food. Xylem also makes the plant strong (wood), so it can stand tall and reach the light.
i.

Observe the figure and answer the questions.

ABC
Figure 5.15
  • i.Name the muscular tissues shown.
  • ii.Name one organ where each is found.
  • iii.Write one function of each.
Answer
  • i.A: skeletal (striped) muscle; B: cardiac muscle; C: smooth (unstriped) muscle.
  • ii.A: attached to the bones of the arm (biceps); B: the heart; C: the stomach (or intestine, or blood vessels).
  • iii.A: moves the bones at will, such as bending the arm; B: contracts rhythmically to pump blood (the heartbeat); C: pushes food along the food canal by slow, involuntary contractions.
j.

Study the figure and answer the questions.

abc
Figure 5.16
  • i.Identify the figure.
  • ii.Name the parts a, b and c.
  • iii.Write the function of a, b and c.
Answer
  • i.A neuron (nerve cell).
  • ii.a: dendrites; b: axon (with its myelin sheath and axon terminals); c: cell body (cyton).
  • iii.a: dendrites receive messages from other neurons or sense cells and carry them to the cell body. b: the axon carries messages away from the cell body to the next neuron, a muscle or a gland; its myelin sheath speeds the message up. c: the cell body holds the nucleus and keeps the neuron alive; messages pass through it from the dendrites to the axon.

5. Project work

5.2 Human nervous system

How do you know that the dal is too hot, that a bus is coming, or that someone has called your name? And how does your stomach “know” to start digesting while your feet walk you home? Something must collect information, decide, and send orders, all the time.

We learn about the things around us through our sense organs (eyes, ears, nose, tongue, skin). The messages they pick up are carried by nervous tissue to the brain, which makes sense of them and decides what to do; then orders go out to the muscles and glands. A change around us that we react to is a stimulus (plural stimuli), and what we do is the response. The system of organs that does all this, the brain, the spinal cord and the nerves, is the nervous system. The sense organs are its outposts.

By its parts and their work, the human nervous system is divided into three parts:

  1. the central nervous system (CNS)
  2. the peripheral nervous system (PNS)
  3. the autonomic nervous system (ANS)
Nervous systemCentral (CNS)Peripheral (PNS)Autonomic (ANS)brainspinal cordcranial nerves12 pairsspinal nerves31 pairssympatheticparasympathetic
Figure 5.17 The parts of the human nervous system.

1. Central nervous system

The central nervous system is the part that runs down the middle of the body, from the head to the lower back. It is made of the brain and the spinal cord, and it is built of a huge number of neurons and their supporting cells. It is the control center: messages come in to it, and orders go out from it.

(a) Brain

The brain is the largest and topmost part of the central nervous system. It lies inside the skull (the cranium), which protects it. It controls and coordinates every part of the body. An adult brain weighs about 1.3 to 1.4 kg.

The brain is wrapped in three layers of membrane, the meninges. From the outside in:

  1. the dura mater, a tough layer stuck to the inside of the skull;
  2. the arachnoid, a thin layer with web-like threads (arachne is Greek for spider);
  3. the pia mater, a very thin layer that clings to the surface of the brain and follows all its folds.

The space between the arachnoid and the pia mater is filled with a clear, watery liquid, the cerebrospinal fluid (CSF). It contains water, minerals, glucose and a little protein, and is slightly alkaline. CSF protects the brain like a water cushion (the brain floats in it, so a bump on the head is softened), and brings it nutrients. The same meninges and CSF surround the spinal cord.

skull (bone)dura mater: tough, on the skullarachnoid: thin, web-like threadscerebrospinal fluid (CSF)pia mater: very thin, on the braingray matter (folded surface)white matter
Figure 5.18 From the skull into the brain: the three meninges (dura mater, arachnoid, pia mater), with cerebrospinal fluid between the arachnoid and the pia mater.

The main parts of the brain are the cerebrum, the cerebellum and the medulla oblongata.

cerebrum (large brain)folded surface: gray mattercerebellum(small brain)ponsmedulla oblongataspinal cordmidbrain, pons and medullatogether: the brainstem← facetemporal lobe
Figure 5.19 The human brain from the left side.

(i) Cerebrum

The cerebrum (the large brain) is the largest part of the brain: about four-fifths of it. A deep groove from front to back divides it into a left and a right cerebral hemisphere (half-spheres). Its surface is folded into ridges and grooves (convolutions), which pack a much bigger surface into the skull. The outer layer is gray matter (cell bodies of neurons); inside it is white matter (axons with myelin).

The cerebrum is the seat of thinking and awareness. It:

  • recognizes smells, and makes sense of what we see, hear, taste and touch;
  • controls speech, memory and hearing;
  • creates consciousness, thought, feelings and imagination;
  • lets us analyze, put ideas together, predict and decide;
  • controls our voluntary movements, and the other parts of the brain.

If the cerebrum is badly injured, a person may lose consciousness and fall into a coma, lose memory or imagination, or lose the power to coordinate and control movements.

(ii) Cerebellum

The cerebellum (the small brain) is the second largest part, about a tenth of the brain’s volume. It lies at the back, below the cerebrum and above the medulla oblongata, in two rounded halves. Like the cerebrum, it has gray matter outside and white matter inside, and fine parallel folds. It:

  • coordinates muscular movements, getting their timing right;
  • keeps the body balanced (in equilibrium) while we walk, run or ride a bicycle;
  • helps control voluntary movements, making them smooth and accurate;
  • keeps the muscle tone and posture of the body.

If the cerebellum is injured, a person’s movements become shaky and they lose their balance. Alcohol affects the cerebellum, which is why a drunk person staggers and can’t walk in a straight line.

(iii) Medulla oblongata

The brainstem joins the brain to the spinal cord, and has three parts: the midbrain, the pons and the medulla oblongata. The midbrain and pons act as bridges, passing messages between the spinal cord and the higher parts of the brain.

The medulla oblongata is the lowest part of the brain, between the pons and the spinal cord. It is shaped like a short stalk or tube. It passes out of the skull through a large opening in its base, the foramen magnum, and continues as the spinal cord. It controls the involuntary actions that keep us alive:

  • it regulates breathing and the heartbeat;
  • it controls vomiting, coughing, sneezing and swallowing;
  • it controls the narrowing and widening of blood vessels, and so the blood pressure;
  • it controls the flow of saliva and digestive juices.

Because breathing and the heartbeat depend on it, a serious injury to the medulla oblongata can kill a person almost at once.

A man has had too much alcohol. He can still talk and think, but he sways and can’t walk along a straight line. Which part of his brain is affected most?

Pick an answer to see why.

(b) Spinal cord

The spinal cord is a long, soft, jelly-like cord that runs down through the canal inside the backbone (vertebral column), which protects it. It starts at the bottom of the medulla oblongata and ends at about the first or second lumbar vertebra in the lower back. It is about 45 cm long and roughly 1–2 cm thick, and is covered by the same meninges as the brain, with CSF around it.

Unlike the brain, the spinal cord has white matter outside and gray matter inside (the gray matter is shaped like a butterfly, or the letter H). A tiny central canal full of CSF runs down its middle.

The spinal cord does two jobs:

  1. it carries messages between the brain and the body, up and down;
  2. it is the center for most reflex actions (see below).
cord ends near the2nd lumbar vertebraspinal cord,about 45 cmstarts at the medullaoblongata (brain above)backbone(vertebrae)backfrontsensory root(message comes in)ganglionmotor root(message goes out)spinalnervewhite matter (outside)gray matter (inside)central canal (CSF)
Figure 5.20 The spinal cord inside the backbone, and cut across.

Nerve fibers

A nerve is a bundle of nerve fibers (axons), wrapped like the wires in a cable. Nerves carry messages to and from the brain and spinal cord. By their job, nerve fibers are of three kinds:

  1. Sensory (afferent) nerves carry messages from the receptors (the sense organs) to the brain or spinal cord.
  2. Motor (efferent) nerves carry orders from the brain or spinal cord to the muscles and glands, the effectors.
  3. Connecting neurons (interneurons, relay neurons) inside the brain and spinal cord link sensory neurons to motor neurons, passing the message from one to the other.

Which nerve carries an order from the spinal cord to the muscle of your arm?

Pick an answer to see why.

2. Peripheral nervous system

The peripheral nervous system (PNS) is made of all the nerves that branch out from the brain and the spinal cord to every part of the body (periphery means the outer edge). It links the central nervous system with the sense organs, muscles and glands. By where the nerves start, there are two kinds:

  1. Cranial nerves arise from the brain. There are 12 pairs. They connect the brain with the organs of the head and face, such as the eyes, ears, nose and tongue (one pair, the vagus nerve, goes further, down to the heart, lungs and stomach).
  2. Spinal nerves arise from the spinal cord. There are 31 pairs. Each carries messages both ways between the spinal cord and a part of the body: sensory fibers come in through the back (dorsal) root, and motor fibers go out through the front (ventral) root.

Reflex action

You slip on a wet path and your hands shoot out to catch you before you even think “I’m falling”. You touch a hot pan and your hand jerks away. Dust flies towards your eye and you blink. These are reflex actions: sudden, automatic, involuntary responses to a stimulus, made without thinking about them. They protect us from harm, and because they don’t wait for the brain to decide, they are very fast. Most reflex actions of the body are controlled by the spinal cord.

The path a message takes in a reflex action is called a reflex arc. For touching a hot object:

  1. Receptor: nerve endings in the skin of the finger sense the heat (the stimulus) and start a nerve impulse.
  2. Sensory nerve: carries the impulse from the receptor to the spinal cord.
  3. Connecting neuron (interneuron): inside the gray matter of the spinal cord, links the sensory nerve to a motor nerve.
  4. Motor nerve: carries the impulse from the spinal cord to the muscle.
  5. Effector: the muscle (here, the biceps of the upper arm) contracts and pulls the hand away.

Receptor → sensory nerve → spinal cord (connecting neuron) → motor nerve → effector. At the same time, a message goes up the spinal cord to the brain, and you feel the pain and know what happened, but only after your hand has already moved.

The reflex arc, slowed down

Touch the hot pan and follow the message. Watch which arrives first: the hand pulling away, or the “Ouch!” in the brain.

Ouch!1 receptor(fingertip skin)2 sensory nerve3 connecting neuron4 motor nerve5 effector:bicepsbrainspinalcordganglionmagnified,cut across

Press “Touch the hot pan”, or go one step at a time. It is shown about 30 times slower than real life.

3. Autonomic nervous system

Some organs work day and night without our control: the heart, the lungs, the kidneys, the stomach and intestine, the glands. The part of the nervous system that controls these involuntary actions, whether we are asleep or awake, is the autonomic nervous system (ANS) (autonomic means self-governing). It controls smooth muscle, cardiac muscle and many glands. It has two parts, which work against each other, like an accelerator and a brake:

  1. Sympathetic nervous system: gets the body ready to face an emergency: to fight or to run (“fight or flight”). It speeds up the heartbeat and breathing, raises the blood pressure, widens the pupils and sends more blood and sugar to the muscles, so the body has more energy to protect itself. It slows digestion, which can wait.
  2. Parasympathetic nervous system: calms the body down once the danger has passed and brings the heartbeat, blood pressure and breathing back to normal. It runs the body’s quiet, everyday work, such as digestion (“rest and digest”).

Fight or flight, rest and digest

The same body, two systems. Press the buttons and watch six organs change.

PupilssmallHeartslowBreathingslowSalivaplentyDigestionbusySkindry, calm70 beats a minute14 breaths a minute
In charge now
parasympathetic system
Gets the body ready to
rest and digest

Calm: the parasympathetic system is in charge. Heart and breathing are slow, the pupils small, and the body gets on with digesting food. This is “rest and digest”.

Sympathetic nervous system Parasympathetic nervous system
Prepares the body for an emergency. Calms the body after an emergency; keeps up normal work.
Speeds up the heartbeat; raises blood pressure. Slows the heartbeat; lowers blood pressure.
Faster breathing. Slower breathing.
Widens (dilates) the pupils. Narrows the pupils.
Slows digestion; less saliva (dry mouth). Speeds up digestion; more saliva.

Exercise (5.2 Nervous system)

1. Choose the correct answer

a. Which is the right order of the meninges, from outside to inside?

Pick an answer to see why.

b. Which part of the nervous system is ash-colored (gray)?

Pick an answer to see why.

c. Injury to which part of the brain can leave a person in a coma?

Pick an answer to see why.

d. Which nerve carries messages from the parts of the body to the brain?

Pick an answer to see why.

e. Which part of the nervous system controls reflex actions?

Pick an answer to see why.

2. Give reasons

a.

A person may go into a coma when the large brain (cerebrum) is injured.

Answer

The cerebrum is the part of the brain that creates consciousness, thought, memory and awareness, and controls the other parts of the brain. When it is badly injured, these functions stop, so the person loses consciousness and may remain unconscious, in a coma.

b.

The hand is pulled away at once when a finger touches a hot object.

Answer

It is a reflex action. The heat stimulates receptors in the skin; the impulse goes along a sensory nerve to the spinal cord, where a connecting neuron passes it straight to a motor nerve; the motor nerve makes the arm muscle contract and pull the hand away. Because the message doesn’t have to go to the brain and wait for a decision, the response is very fast and protects the hand from a burn.

c.

The body loses its balance when the cerebellum is injured.

Answer

The cerebellum coordinates the muscles’ movements, times them, and keeps the body balanced while we walk, run or stand; it also keeps muscle tone and posture. When it is injured, this coordination fails: movements become shaky and unbalanced, and the person staggers or falls, as someone who has drunk too much alcohol does.

d.

The spinal cord is called the center of reflex action.

Answer

In a reflex action, the message from the receptor travels along a sensory nerve to the spinal cord, and it is there, in the gray matter, that a connecting neuron passes it to a motor nerve, which carries the response to the muscle. The brain is not needed for the response. Since the spinal cord receives the message and sends out the response, it is called the center of reflex action.

3. Write the differences

a.

Cranial nerves and spinal nerves

Answer
Cranial nerves Spinal nerves
Arise from the brain. Arise from the spinal cord.
12 pairs. 31 pairs.
Mostly serve the head and face (eyes, ears, nose, tongue). Serve the neck, trunk, arms and legs.
Some are only sensory, some only motor, some mixed. All are mixed (sensory and motor fibers).
b.

Sensory nerves and motor nerves

Answer
Sensory (afferent) nerves Motor (efferent) nerves
Carry messages from the receptors (sense organs) to the brain or spinal cord. Carry orders from the brain or spinal cord to the effectors (muscles, glands).
Start at the receptors. End at the effectors.
Enter the spinal cord through the dorsal (back) root. Leave the spinal cord through the ventral (front) root.
c.

Cerebrum and cerebellum

Answer
Cerebrum Cerebellum
The large brain: the biggest part, about four-fifths of the brain. The small brain: about a tenth of the brain.
Lies at the top and front, divided into two cerebral hemispheres. Lies at the back, below the cerebrum.
Has deep, irregular folds. Has fine, parallel folds.
Controls thinking, memory, speech, the senses, consciousness and voluntary actions. Coordinates movements, keeps balance, muscle tone and posture.
Injury may cause coma or loss of memory. Injury causes loss of balance and shaky movements.
d.

Sympathetic and parasympathetic nervous system

Answer
Sympathetic Parasympathetic
Prepares the body for an emergency (fight or flight). Brings the body back to normal after an emergency (rest and digest).
Increases heartbeat and blood pressure. Decreases heartbeat and blood pressure.
Speeds up breathing. Slows down breathing.
Widens the pupils. Narrows the pupils.
Slows digestion. Speeds up digestion.

4. Answer the following questions

a.

Draw a neat diagram of the brain and label its parts.

Answer

Draw it as in Figure 5.19: the large, folded cerebrum on top; the cerebellum at the back underneath it, with fine parallel folds; the pons and the medulla oblongata below, leading down into the spinal cord. Label each part.

b.

What are the functions of the medulla oblongata? Explain.

Answer

The medulla oblongata, the lowest part of the brainstem, controls the involuntary actions that keep us alive:

  1. It regulates breathing (the rate and depth of respiration).
  2. It controls the heartbeat.
  3. It controls the narrowing and widening of blood vessels, and so the blood pressure.
  4. It controls reflexes such as vomiting, coughing, sneezing and swallowing.
  5. It controls the secretion of saliva and digestive juices.

It also passes messages between the spinal cord and the rest of the brain. Because breathing and the heartbeat depend on it, an injury to it can cause death at once.

c.

What is the work of the autonomic nervous system? Describe it with a diagram.

Answer

The autonomic nervous system controls the involuntary actions of the internal organs, such as the heart, lungs, kidneys, stomach, intestine, blood vessels and glands, all the time, asleep or awake, without our will. It has two parts that work against each other:

  • the sympathetic system prepares the body for an emergency: it speeds up the heartbeat and breathing, raises the blood pressure, widens the pupils and slows digestion;
  • the parasympathetic system brings the body back to rest: it slows the heartbeat and breathing, lowers the blood pressure, narrows the pupils and speeds up digestion.

Diagram: draw the spinal cord with nerves from it to the eye, heart, lungs, stomach and intestine; on one side mark the effects of the sympathetic system, on the other those of the parasympathetic system (the organs in the widget above show them).

d.

Describe the reflex action that happens when we touch a hot object.

Answer

When the finger touches a hot object:

  1. Receptors (nerve endings) in the skin sense the heat and start an impulse.
  2. A sensory nerve carries it to the spinal cord.
  3. In the spinal cord, a connecting neuron passes it to a motor nerve.
  4. The motor nerve carries the impulse to the muscles of the arm (the effector).
  5. The muscles contract and the hand is pulled away.

This path, receptor → sensory nerve → spinal cord → motor nerve → effector, is the reflex arc. The message reaches the brain only afterwards, and then we feel the pain.

e.

What is the nervous system? Describe its kinds briefly.

Answer

The nervous system is the system of the brain, spinal cord and nerves that receives information about changes inside and outside the body, makes sense of it, and controls and coordinates the activities of all the organs. Its three parts:

  1. Central nervous system: the brain and spinal cord; the control center.
  2. Peripheral nervous system: the 12 pairs of cranial nerves and 31 pairs of spinal nerves, which link the CNS with the sense organs, muscles and glands.
  3. Autonomic nervous system: sympathetic and parasympathetic; controls the involuntary actions of the internal organs.
f.

Write the functions of the small brain, the large brain and the spinal cord.

Answer

Small brain (cerebellum): coordinates muscular movements; keeps the body balanced; keeps muscle tone and posture; makes voluntary movements smooth.

Large brain (cerebrum): thinking, memory, intelligence, imagination and consciousness; speech; makes sense of sight, hearing, smell, taste and touch; controls voluntary actions and the other parts of the brain.

Spinal cord: carries messages between the brain and the body; is the center of reflex actions.

g.

What is a neuron? Draw a neat diagram, label its parts and write the function of each part.

Answer

A neuron (nerve cell) is the structural and functional unit of the nervous system, a cell that carries messages (nerve impulses). Draw it as in Figure 5.13.

  • Dendrites: receive messages from other cells and carry them towards the cell body.
  • Cell body (cyton): holds the nucleus; keeps the neuron alive; passes the message on to the axon.
  • Axon: carries messages away from the cell body.
  • Myelin sheath: insulates the axon and makes the message travel faster.
  • Axon terminals: pass the message to the next neuron, a muscle or a gland.
h.

Describe reflex action, with examples.

Answer

A reflex action is a quick, automatic, involuntary response to a stimulus, made without thinking, and controlled mostly by the spinal cord. It protects the body from harm. Examples: pulling the hand away from a hot object or a thorn; blinking when something comes towards the eye; the knee jerk; sneezing and coughing; putting the hands out when we slip. The message travels along a reflex arc: receptor → sensory nerve → spinal cord (connecting neuron) → motor nerve → effector (muscle or gland).

i.

Study the diagram and answer the questions.

ABC
Figure 5.21
  • i.Name the parts marked A, B and C.
  • ii.Write the functions of A, B and C.
  • iii.What happens if part C is injured?
Answer
  • i.A: cerebrum; B: cerebellum; C: medulla oblongata.
  • ii.A: thinking, memory, speech, the senses, consciousness and voluntary actions. B: balance, posture and the coordination of movements. C: breathing, heartbeat, blood pressure, and reflexes such as swallowing, coughing, sneezing and vomiting.
  • iii.Breathing and the heartbeat can stop, so an injury to the medulla oblongata can kill a person almost at once.

5.3 Human glandular system

You hear a loud bang at night. In a moment your heart is pounding, and it keeps pounding for minutes after you know it was only a firecracker. A nerve message is over in a flash; what keeps the heart racing is a chemical carried in your blood. Chemicals like this are made by glands.

A gland is a cell or group of cells (an organ) that makes a useful substance and pours it out (secretes it): hormones, enzymes, and juices such as sweat, saliva and tears. These secretions control many activities and keep the body healthy, helping in digestion, reproduction, excretion and growth. All the glands of the body together make up the glandular system. By how they deliver their secretion, glands are of two main kinds: exocrine and endocrine.

GlandsExocrinewith ductsEndocrineductless: hormonesMixedbothsweat glandssalivary glandstear glandspituitarythyroidparathyroidadrenalpancreasgonads (testes, ovaries)
Figure 5.22 The kinds of glands.

A) Exocrine glands

An exocrine gland pours its secretion through a duct (a small tube) to the place where it is needed. Examples: sweat glands (onto the skin), salivary glands (into the mouth), tear glands (onto the eyes), the liver (bile into the intestine). They are also called duct glands. Their secretions do important work in digestion and excretion; many contain enzymes, which act as biological catalysts: they speed up chemical reactions in the body, such as breaking down food, without being used up.

B) Endocrine glands

An endocrine gland has no duct (it is a ductless gland). It releases its secretion straight into the blood, which carries it all over the body. This secretion is called a hormone. A hormone is made in one place but works in another, often far away: it stimulates and regulates particular body cells, organs and other glands. That is why hormones are called chemical messengers. The pituitary, thyroid, parathyroid and adrenal glands are endocrine glands, and together the endocrine glands make up the endocrine system.

Too much or too little of a hormone causes problems: it can upset growth and development, weaken the power to reproduce, or cause disease.

Mixed glands

Some glands do both: they release enzymes through a duct and hormones into the blood. They are called mixed glands (both exocrine and endocrine). The pancreas is the main example: it sends digestive juice down a duct to the intestine, and the hormones insulin and glucagon into the blood. The gonads (testes and ovaries) are also often counted as mixed glands: they release sex cells (sperm, ova) through tubes and hormones into the blood.

pineal glandpituitary glandthyroid glandparathyroid glands (behind the thyroid)thymusadrenal glands (on the kidneys)pancreasovaries (in a woman)testes(in a man, in the scrotum,outside the abdomen)
Figure 5.23 The endocrine glands of the human body.

Functions of hormones

  1. They bring about physical, mental and emotional growth and development.
  2. They stimulate and control various organs.
  3. They control the production of sperm and ova (egg cells).
  4. They develop the sexual characters (the changes of puberty).
  5. They control the power to reproduce.
  6. They keep the calcium and phosphorus in the body balanced.
  7. They keep the level of sugar in the blood steady.
Gland Where it is Hormone(s) Main job
1.Pituitary at the base of the brain growth hormone, stimulating hormones growth; controls other glands
2.Thyroid in the neck, on the windpipe thyroxine (also T₃ and calcitonin) rate of body chemistry (metabolism), growth
3.Parathyroid behind the thyroid, in the neck parathormone raises calcium in the blood
4.Adrenal on top of each kidney adrenaline, cortisol emergencies, stress
5.Pancreas behind the stomach, in the loop of the duodenum insulin, glucagon blood sugar
6.Gonads: testes in the scrotum (men) testosterone sperm; male characters
Gonads: ovaries in the lower abdomen (women) estrogen, progesterone ova; female characters

Pituitary gland

The pituitary gland is about the size of a pea. It hangs from the base of the brain, inside the skull. It makes growth hormone and several stimulating hormones, which control the thyroid, adrenal glands and gonads. Because it coordinates and controls the other endocrine glands, it is called the master gland. (The pituitary itself takes orders from the part of the brain just above it, the hypothalamus.)

Growth hormone controls the growth of the body. If a child makes too little of it, the child grows up very short: dwarfism. If a child makes too much, the child grows unusually tall: gigantism.

Thyroid gland

The thyroid gland is shaped like a butterfly: two lobes, one on each side of the windpipe in the neck, joined by a thin band of tissue. It makes three hormones: thyroxine (T₄), triiodothyronine (T₃) and calcitonin.

Thyroxine controls how fast the body’s cells use food and oxygen (the metabolism), and it is needed for normal physical and mental growth. About two-thirds (65 %) of a thyroxine molecule by mass is iodine, so our food must contain iodine; that is why the salt sold in Nepal has iodine added (iodized salt). If there is too little iodine, the thyroid swells up: a goiter.

  • Too little thyroxine: tiredness, weakness of body and mind, dry skin, little sweating, slow and slurred speech, a hoarse voice. In babies and children it slows growth and mental development.
  • Too much thyroxine: the metabolism speeds up: heavy sweating, great hunger but loss of weight, nervousness and restlessness, and bulging eyes.

Calcitonin lowers the calcium in the blood by laying it down in the bones.

Parathyroid glands

There are four small parathyroid glands, at the back of the thyroid. They make parathormone, which moves calcium between the bones and the blood and raises the calcium level in the blood.

  • Too much parathormone (usually because of a small tumor in one of the glands): too much calcium is taken from the bones into the blood; the bones become weak, and kidney stones may form.
  • Too little: the calcium in the blood falls and the muscles go into painful cramps and spasms: tetany.

Adrenal glands

An adrenal gland sits on top of each kidney, like a cap. It makes adrenaline and cortisol (called cortisone in many books), along with a few other hormones.

  • Adrenaline prepares the body to face a sudden emergency or danger: it makes the heart beat faster, raises the blood pressure and releases sugar into the blood. It works hand in hand with the sympathetic nervous system. Too much adrenaline raises the blood pressure.
  • Cortisol helps the body cope with stress and controls the use of sugar; the adrenals also make small amounts of sex hormones.

When the adrenal glands make too little of their hormones, a person feels weak, the blood pressure and blood sugar fall, and they may feel sick and vomit.

Pancreas

The pancreas is one of the largest glands of the body, about 12–15 cm long. It lies behind the stomach, in the loop of the duodenum (the first part of the small intestine). It is a mixed gland:

  • as an exocrine gland, it makes pancreatic juice, full of digestive enzymes, which flows through a duct into the duodenum;
  • as an endocrine gland, small clusters of cells in it (the islets of Langerhans) release two hormones into the blood: insulin and glucagon.

Insulin lowers the blood sugar: it lets the body’s cells take in glucose, and the liver store it. Glucagon raises the blood sugar: it makes the liver release its stored sugar. Because they do opposite jobs, they are called antagonistic hormones, and together they keep the blood sugar steady.

  • Too little insulin: the glucose in the blood stays high. This is diabetes (diabetes mellitus). A person with diabetes feels very hungry and thirsty and passes urine often.
  • Too much insulin: the blood glucose falls too low. The person feels anxious, shaky and sweaty, may become confused and faint, and in severe cases may fall into a coma, with damage to the brain.

Insulin and glucagon at work

Live through a day: eat, play and wait, two hours at a time. Then switch to “too little insulin” and live the same day with diabetes.

408012016020024028006:0010:0014:0018:0022:0002:0006:00↑ normal range (70–140)sugar spills into the urine (above about 180)mg/dL
The next two hours
Pancreas
Time
06:00
Blood sugar
88 mg/dL
The pancreas is sending out
too little insulininsulin (sugar ↓)glucagon (sugar ↑)a little of each

Start the day: eat, play or wait, two hours at a time, and watch the blood sugar.

Gonads

The testes in males and the ovaries in females are called the gonads.

  • Testes: two oval glands in a pouch of skin, the scrotum. They make sperm and the hormone testosterone. Testosterone helps make sperm and brings the secondary sexual characters of boys at puberty: hair on the face, a deeper voice, growth of the sex organs and muscles.
  • Ovaries: two oval glands in the lower abdomen of a woman, beside the uterus and near the fallopian tubes. They make ova (egg cells) and the hormones estrogen and progesterone, which help the ova to develop and bring the female sexual characters at puberty, and prepare the uterus for a baby.

Which gland is called the master gland?

Pick an answer to see why.

A boy’s mother forgot to buy iodized salt for years. Which gland is most likely to be affected?

Pick an answer to see why.

Nerves and hormones work together

The nervous system and the glands are the body’s two message systems. Nerves send fast electrical messages along fixed wires to particular muscles and glands; hormones send slower chemical messages through the blood to every cell that can read them. They are linked: the hypothalamus in the brain controls the pituitary, and so most of the other glands; and in a fright, sympathetic nerves tell the adrenal glands to pour out adrenaline, which keeps the body ready long after the nerve messages have stopped.

Nervous system Endocrine (glandular) system
Messages are electrical impulses along nerves. Messages are chemicals (hormones) in the blood.
Very fast. Slower.
Effects are short-lived. Effects can last a long time (growth lasts years).
Go to particular muscles and glands. Reach the whole body; only the target cells respond.

5.4 Plant hormone

Put a pot of seedlings on a windowsill, and in a few days they all lean towards the window. Plants have no nerves and no glands. So how does a plant “know” where the light is, and how does it bend towards it?

Plants, too, respond to changes in their surroundings: to light, to gravity, to chemicals and to touch. A shoot grows towards the light (phototropism); a root grows down, with gravity (geotropism); a climbing bean’s tendril coils around a stick it touches. They need special substances at special times and places to grow, to flower, to set fruit, to ripen it and to drop their leaves and seeds. These substances are plant hormones.

Plant hormones are not nutrients. They are made in tiny amounts by ordinary cells in particular parts of the plant (plants have no glands like ours), and they carry messages from one cell to another: they are chemical messengers, like animal hormones.

The growth of a plant depends on external (environmental) factors, such as light, water and temperature, and on internal factors. The most important internal factor is its hormones. The hormones that support and regulate the growth and development of a plant are called plant growth hormones (plant growth regulators). Examples: auxin, gibberellin, cytokinin, ethylene and brassinosteroids.

Functions of plant growth hormones

The main job of growth hormones is to regulate the growth and development of the plant. Most are made in the growing regions, such as the tips of the shoot and root.

  • Auxin is made in the tip of the shoot. It moves down the stem and makes the cells grow longer. When light falls on a shoot from one side, auxin moves to the shaded side; those cells grow longer than the ones on the lit side, so the shoot bends towards the light. This is phototropism. Auxin from the tip also keeps the side buds from growing, so the plant grows tall rather than bushy: this is apical dominance (Activity 5.1).
  • Cytokinin is found in large amounts in the root tips, embryos (young plants in seeds) and fruits. It makes cells divide, helps side buds to grow, and keeps leaves green and fresh for longer.
  • Gibberellin makes stems grow long and helps seeds sprout; farmers use it to make grapes and other fruits bigger.
  • Ethylene is a gas. It makes fruits ripen, and makes old leaves and ripe fruits fall off (abscission).
  • Brassinosteroids help cells grow and divide and help the plant cope with stress.

Make the seedling bend

Drag the lamp around the seedling. Then cover its tip with foil, or cut the tip off, and try again.

Drag the lamp. Red dots: auxin.

Tip:

Light from one side: auxin moves to the shaded side of the shoot. The cells there grow longer than the cells on the lit side, so the shoot bends towards the light.

Uses of plant growth hormones

  1. Tissue culture. A few cells or a tiny piece of a plant are grown on a jelly of nutrients in a clean glass container, with auxin and cytokinin added to it. More auxin makes roots start; more cytokinin makes shoots grow; the right balance of the two gives fast, healthy growth. In this way, thousands of identical, disease-free plantlets (of bananas, potatoes, orchids, flowers) can be grown from one plant, in labs in Nepal too.
  2. Better and off-season crops. Hormones help farmers grow good-quality fruit and vegetables, and vegetables out of season: auxin helps cuttings take root and fruits set; gibberellin makes fruits bigger; ethylene ripens fruits evenly.

But hormones sprayed on vegetables and fruits in large amounts can harm the health of the people who eat them. They must be used only in the right amounts and at the right time, as experts advise.

A row of glass flasks on a shelf, each with a few small green plantlets growing on a pale jelly at the bottom
Figure 5.24 Tissue culture: small plants growing on a jelly of nutrients and hormones in clean glass flasks. One plant can give thousands like these. Photo: Syed Sajidul Islam, CC BY-SA 4.0

Exercise (5.3 Glands and 5.4 Plant hormone)

1. Choose the correct answer

a. Which hormone controls the sugar level in the blood?

Pick an answer to see why.

b. Which hormone ripens fruit?

Pick an answer to see why.

c. Which hormone causes apical dominance?

Pick an answer to see why.

d. Which gland is called the master gland?

Pick an answer to see why.

e. Which hormone develops and controls the male sexual characters?

Pick an answer to see why.

f. Which hormone is involved in the ripening of fruit and the falling of leaves?

Pick an answer to see why.

2. Give reasons

a.

The pancreas is called a mixed gland.

Answer

The pancreas works both as an exocrine gland and as an endocrine gland. It makes pancreatic juice, full of enzymes, which goes through a duct to the duodenum; and its islets of Langerhans release the hormones insulin and glucagon straight into the blood. Since it has both kinds of secretion, it is a mixed gland.

b.

The pituitary gland is called the master gland.

Answer

The pituitary makes stimulating hormones that control the working of the other endocrine glands, such as the thyroid, the adrenal glands and the gonads, as well as growth hormone. Because it coordinates and controls the other glands, it is called the master gland.

c.

A hormone is called a chemical messenger.

Answer

A hormone is a chemical made in an endocrine gland, but it does its work somewhere else: it is carried by the blood to particular cells and organs, often far away, and changes what they do. Since it carries a “message” from the gland to its target, it is called a chemical messenger.

d.

Glucagon and insulin work against each other.

Answer

Insulin lowers the blood sugar: it helps the cells take in glucose and the liver store it. Glucagon raises the blood sugar: it makes the liver release its stored sugar into the blood. Their effects are opposite, so they are called antagonistic hormones; together they keep the blood sugar steady.

e.

An enzyme is called a biological catalyst.

Answer

A catalyst is a substance that speeds up a chemical reaction without being used up in it. Enzymes are proteins made by living cells that speed up the chemical reactions of the body, such as the digestion of food, without being used up. Since they are catalysts made by and working in living things, they are called biological catalysts.

3. Write the differences

a.

Exocrine and endocrine glands

Answer
Exocrine gland Endocrine gland
Has a duct (duct gland). Has no duct (ductless gland).
Pours its secretion through the duct to a particular place. Releases its secretion straight into the blood.
Secretions: enzymes, sweat, saliva, tears. Secretions: hormones.
Acts near the gland. Acts far from the gland.
e.g. sweat, salivary and tear glands e.g. pituitary, thyroid, adrenal
b.

Cytokinin and auxin

Answer
Cytokinin Auxin
Found mostly in root tips, embryos and fruits. Made mostly in the shoot tip.
Makes cells divide. Makes cells grow longer.
Helps side buds to grow. Keeps side buds from growing (apical dominance).
Keeps leaves green and delays their aging. Makes shoots bend towards light (phototropism).
In tissue culture, more cytokinin forms shoots. In tissue culture, more auxin forms roots.
c.

Parathyroid and thyroid glands

Answer
Parathyroid glands Thyroid gland
Four small glands. One butterfly-shaped gland with two lobes.
At the back of the thyroid. On the windpipe in the neck.
Make parathormone. Makes thyroxine, T₃ and calcitonin.
Raises the calcium in the blood. Controls metabolism and growth (calcitonin lowers blood calcium).
Too little: tetany. Too much: kidney stones, weak bones. Too little iodine: goiter. Too much thyroxine: sweating, weight loss, bulging eyes.

4. Answer the following questions

a.

What is a gland? Make a chart of its kinds, with examples.

Answer

A gland is a cell or an organ that makes a useful substance (a secretion, such as a hormone, an enzyme or a juice) and releases it. Chart (Figure 5.22):

  • Exocrine (duct) glands: sweat glands, salivary glands, tear glands.
  • Endocrine (ductless) glands: pituitary, thyroid, parathyroid, adrenal.
  • Mixed glands: pancreas, gonads (testes, ovaries).
b.

What are plant hormones? Write about them.

Answer

Plant hormones are chemical substances made in small amounts in certain parts of a plant (mainly the growing tips) that travel to other parts and control its growth and development. They are not nutrients but chemical messengers. They control how a plant grows taller and thicker, bends towards light, forms roots and shoots, flowers, sets and ripens fruit, and drops its leaves. Examples: auxin (cell lengthening, phototropism, apical dominance), gibberellin (stem lengthening), cytokinin (cell division), ethylene (ripening and leaf fall) and brassinosteroids.

c.

Draw a diagram of the endocrine glands in the human body.

Answer

Draw a body outline as in Figure 5.23 and mark: the pituitary at the base of the brain; the thyroid in the neck, with the parathyroids behind it; the adrenals on top of the kidneys; the pancreas behind the stomach; the ovaries in the lower abdomen (or the testes in the scrotum).

d.

Describe the pituitary gland briefly.

Answer

The pituitary gland is a pea-sized endocrine gland hanging from the base of the brain, inside the skull. It makes growth hormone, which controls the growth of the body, and stimulating hormones, which control other endocrine glands such as the thyroid, the adrenals and the gonads; so it is called the master gland. Too little growth hormone in childhood causes dwarfism (very short height); too much causes gigantism (very great height).

e.

List the plant hormones.

Answer

Auxin, gibberellin, cytokinin, ethylene and brassinosteroids. (Another important one, abscisic acid, helps a plant survive dry spells by closing its stomata.)

f.

Write the uses of plant hormones.

Answer
  1. In tissue culture, auxin and cytokinin are added in the right balance to grow many disease-free plantlets quickly: more auxin forms roots, more cytokinin forms shoots.
  2. Auxin helps cuttings to root and fruits to set.
  3. Gibberellin makes fruits such as grapes bigger and helps seeds sprout.
  4. Ethylene ripens fruits evenly for the market.
  5. Hormones help produce good-quality and off-season vegetables and fruits.

They must be used in small, correct amounts: too much on food crops can harm people’s health.

g.

Describe the pancreas, with a diagram.

Answer

The pancreas is a long, leaf-shaped gland, about 12–15 cm long, behind the stomach, in the loop of the duodenum. Draw it lying across the abdomen with its head in the curve of the duodenum (Figure 5.23). It is a mixed gland:

  • Exocrine part: makes pancreatic juice with digestive enzymes, which flows through the pancreatic duct into the duodenum and helps digest food.
  • Endocrine part: the islets of Langerhans release insulin, which lowers blood sugar, and glucagon, which raises it.

Too little insulin causes diabetes; too much causes very low blood sugar, with shaking, confusion and fainting.

h.

What happens in the human body if too much of a hormone is made? Describe with examples.

Answer
  • Too much growth hormone in childhood: gigantism, the person grows unusually tall.
  • Too much thyroxine: the metabolism speeds up: heavy sweating, hunger, loss of weight, nervousness and bulging eyes.
  • Too much parathormone: calcium leaves the bones, which become weak, and kidney stones may form.
  • Too much adrenaline: high blood pressure.
  • Too much insulin: blood sugar falls too low: anxiety, shaking, fainting, and in severe cases coma.
i.

Describe how the glandular system and the nervous system are related, with examples.

Answer

The two systems work together to control the body. The hypothalamus, a part of the brain, controls the pituitary, which in turn controls the thyroid, adrenals and gonads; so the nervous system controls much of the glandular system. For example, when we are frightened, the sympathetic nerves make the adrenal glands release adrenaline, which keeps the heart racing and the blood sugar high so the body can face the danger. Hormones also affect the nervous system: thyroxine is needed for the normal growth of the brain, and a child without enough of it develops mental disabilities. Nerves give fast, short-lived control; hormones give slower, longer-lasting control.

j.

Observe the diagram and answer the questions.

ABCDEF
Figure 5.25
  • a.Name the glands marked A to F.
  • b.Name the hormone made by each gland, with one function.
  • c.Which hormone is responsible for tetany?
Answer
  • a.A: pituitary; B: thyroid; C: parathyroid; D: adrenal; E: pancreas; F: ovary.
  • b.Each gland’s hormone and one of its functions are in the table below.
  • c.Parathormone: too little of it lowers the calcium in the blood and causes tetany (muscle spasms).
Gland Hormone One function
A pituitary growth hormone controls the growth of the body
B thyroid thyroxine controls metabolism and growth
C parathyroid parathormone raises the calcium in the blood
D adrenal adrenaline prepares the body for an emergency
E pancreas insulin (and glucagon) lowers the blood sugar (glucagon raises it)
F ovary estrogen (and progesterone) develops the female sexual characters
